Schweigen 90cm Silent Undermount Rangehood with Single External ST Motor - Stainless Steel (UM1390-9ST/39cm Depth)
Schweigen 90cm Silent Undermount Rangehood with Single External ST Motor - Stainless Steel (UM1390-9ST/39cm Depth)
$3,499
Schweigen 90cm Silent Undermount Rangehood with Single External ST Motor - Stainless Steel (UM1390-9ST/39cm Depth)
UM1390-9ST
Available on 36 months of equal Interest Free instalments:
approximately per month
^ Total repayments $3,499 (excluding fees). Min purchase of $500 applies. Offer ends 30/09/2026. Equal monthly payments required. Lending criteria, T&Cs & fees apply incl. a $55 estb. fee & $65 annual fee ($32.50 half yearly). Standard interest rate (currently 29.49% p.a.) applies after interest free term ends. Exclusions may apply. *Further information on rates and fees can be found at gemfinance.co.nz. Credit provided by Latitude Financial Services Ltd.
How it worksGem Finance Interest Free
Available on participating Gem credit cards.
New to Gem? Follow the steps below to apply for a Gem Visa now.
Apply Online
Complete your online application in just 10-15 minutes
Credit Check
Submit income, employment details, and expenses. Include proof of income by sharing your online statement or uploading income documents.
Provide Identification
All applicants must provide a form of identification, e.g., NZ driver's license, NZ Passport, or International Passport.
Extended Range Item | Available by Special Order Only
Delivery expectation: 1-2 weeks
This item is available by special order and may not be stocked in stores.
Purchase online today to secure your product. For more information, please
contact your local Harvey Norman store.
Up to $400 CASHBACK* via redemption on eligible Schweigen Rangehoods
Enhance your kitchen ventilation using the Schweigen 90cm Silent Undermount Rangehood with Single External ST Motor. A must-have in your cooking space, this appliance delivers 900 m³/h airflow to reliably capture smoke, steam, and odours. It also packs handy features like edge-to-edge extraction, internal blow, and a touch control panel. Plus, it even flaunts a sleek, stainless steel design that blends well into your cabinetry.
Key Overview
- Maximum Air Flow of 900 m³/h
- Edge-to-Edge Extraction
- Internal Blow Included
- Fan Speed Display
- Removable Grease Filter
- Top Exhaust Vent
- (W x D x H): 898 x 390 x 268 mm
Product Highlights
- Fresher Kitchen Air: Achieve a clean, pleasant atmosphere while you’re cooking using the Schweigen Silent Rangehood. It outputs up to 900 m³/h airflow, which clears away steam and fumes seamlessly.
- Reliable Motor Efficiency: With its single external ST motor, you’ll be able to enjoy superb suction performance while leaving the noise outside.
- Enhanced Filtration: The three mesh filters capture airborne cooking particles, delivering cleaner extraction performance. It is also dishwasher-safe for easy maintenance.
- Breezy Operations: Use the built-in touch control panel to select from its five fan speeds, set the timer, and adjust other settings. It also integrates two 3W lights for incredible illumination.
- Modern Kitchen Style: Beautifully integrate this Schweigen 90cm Rangehood into your modern kitchen, as it flaunts an undermount configuration that fits neatly beneath cabinetry.
*Qualified installer recommended.
| Brand | Schweigen |
|---|---|
| Product Type | Undermount Rangehood |
| Model Number | UM1390-9ST |
| Colour | Stainless Steel |
Rangehood
| Hood Type |
|
|---|---|
| Rangehood Feature/s |
|
Control Panel
| Control Panel Type | Touch Control Panel |
|---|---|
| Location of Control Panel | front |
Fan
| Maximum Air Flow (Cubic Meter Per Hour) | 900 m³/h |
|---|---|
| Number of Fan Speeds | 5 x Fan Speeds |
Lighting
| Lighting Type | LED Lighting |
|---|---|
| Number of Lights | 2 x Lights |
| Number of Light Levels | 1 x Light Level |
| Lighting Power | 2 x 3W |
Motor
| Motor Included | Yes, Included |
|---|
Filter
| Filter Type | Mesh Filter |
|---|---|
| Number of Filters | 3 x Filters |
| Replacement Filter | Yes |
| Filter Feature/s |
|
Vent
| Exhaust Vent Location | Top |
|---|
Ducting
| Duct Shape | Round |
|---|
Power
| Power Source | Corded |
|---|---|
| Power Cable Length | 1.5m |
| Power Connection | 10A plug & lead |
| Power Consumption | 260 mA |
| Voltage | 220-240V |
| Frequency | 50Hz |
| Fuse Rating | 10A |
| Power Feature/s |
|
Installation
| Assembly Type | Installer Required |
|---|---|
| Minimum Installation Height from Cooking Surface (Gas) | 650 mm |
| Minimum Installation Height from Cooking Surface (Electric) | 600 mm |
Dimensions
| Height | 268 mm |
|---|---|
| Width | 898 mm |
| Depth | 390 mm |
| Product Weight | 6.5 kg |
Packaged Dimensions
| Packaged Width | 37.5 cm |
|---|---|
| Packaged Depth | 98.5 cm |
| Packaged Height | 47.5 cm |
| Packaged Weight | 10 kg |
Warranty
| Manufacturer | 60 Months |
|---|
Delivery
We aim to dispatch orders within 2 days. Delivery costs are calculated based on your location and the size of your order. Furniture may take up to 8 weeks to deliver as most products are made specifically for your order. Some Customer Direct products are shipped from overseas and may take longer to arrive. Some goods may take longer to deliver if a product is currently not in stock. A staff member will contact you where this occurs.
Easy returns
If you feel your product has failed a Consumer Guarantee (as defined by New Zealand Consumer Law) then don't worry you can easily return it to your local Harvey Norman store. We'll even pay for the postage if you live in an area where there is no store. Our returns policy covers any purchased item ( conditions apply).
- 1 x Rangehood Body
- 3 x Filters
- 2 x Lights
- 1 x Motor
- 1 x Ducting
- 1 x Wall Bracket
