Smeg 60cm Non-Silent Undermount Rangehood with Onboard Motor - Stainless Steel (KDIAM60AX)
Smeg 60cm Non-Silent Undermount Rangehood with Onboard Motor - Stainless Steel (KDIAM60AX)
$2,499
Smeg 60cm Non-Silent Undermount Rangehood with Onboard Motor - Stainless Steel (KDIAM60AX)
KDIAM60AX
Available on 50 months of equal Interest Free instalments:
approximately per month
^ Total repayments $2,499 (excluding fees). Min purchase of $1,500 applies. Offer ends 14/07/2026. Equal monthly payments required. Lending criteria, T&Cs & fees apply incl. a $55 estb. fee & $65 annual fee ($32.50 half yearly). Standard interest rate (currently 29.49% p.a.) applies after interest free term ends. Exclusions may apply. *Further information on rates and fees can be found at gemfinance.co.nz. Credit provided by Latitude Financial Services Ltd.
How it worksGem Finance Interest Free
Available on participating Gem credit cards.
New to Gem? Follow the steps below to apply for a Gem Visa now.
Apply Online
Complete your online application in just 10-15 minutes
Credit Check
Submit income, employment details, and expenses. Include proof of income by sharing your online statement or uploading income documents.
Provide Identification
All applicants must provide a form of identification, e.g., NZ driver's license, NZ Passport, or International Passport.
Extended Range Item | Available by Special Order Only
Delivery expectation: 1-2 weeks
This item is available by special order and may not be stocked in stores.
Purchase online today to secure your product. For more information, please
contact your local Harvey Norman store.
Keep your cooking area fresh with the Smeg 60cm Non-Silent Undermount Rangehood. Featuring a powerful 275W onboard motor, 679 m³/h airflow, and a removable grease filter, this appliance is built to remove smoke and odours with ease. Its button controls, fan speed display, a dishwasher-safe filter, and LED lighting deliver everyday convenience—all with a clean, contemporary look.
Key Overview
- 60cm Size
- 275W Onboard Motor
- 50-72 dBA Noise Level
- LED Lighting
- Removable Grease Filter
- Automatic Safety Cut Off
- Damper Included
- Top Exhaust Vent
- (W x D x H): 600 x 295 x 315 mm
Product Highlights
- Efficient Ventilation: Designed for cooking spaces, the Smeg Undermount Rangehood features a 275W onboard motor, a powerful 679 m³/h airflow, and four adjustable fan speeds to quickly clear smoke and cooking odours. It also has a built-in damper and delivers a 50-72 dBA noise level.
- Easy-Clean Filter: This Smeg rangehood features a stainless steel baffle filter that capture grease and airborne particles. The filter is dishwasher-safe, making cleaning quick and convenient.
- Optimised Ventilation System: Offering both recirculating and ducted options, along with a top exhaust vent and button controls, this rangehood ensures reliable ventilation for a fresher cooking environment.
- Convenient Controls: Designed for ease of use, the rangehood features a fan speed display for simple and efficient operation.
- Optimum Visibility: Equipped with four LED lights, this rangehood brightly illuminates your cooking space for safer and more precise meal preparation.
- Modern Style: With its sleek profile and polished stainless steel finish, this rangehood enhances your kitchen with a stylish and streamlined look.
*Qualified installer recommended.
| Brand | Smeg |
|---|---|
| Product Type | Undermount Rangehood |
| Model Number | KDIAM60AX |
| Colour | Stainless Steel |
Rangehood
| Hood Type |
|
|---|---|
| Rangehood Feature |
|
Control Panel
| Control Panel Type | Button Controls |
|---|---|
| Location of Control Panel | Front & Under Rangehood |
Fan
| Maximum Air Flow (Cubic Meter Per Hour) | Max Airflow (IEC 61591): 679 m³/h |
|---|---|
| Number of Fan Speeds | 4 x Fan Speeds |
Lighting
| Lighting Type | LED Lighting |
|---|---|
| Number of Lights | 4 x Lights |
| Number of Light Levels | 1 x Light Levels |
| Lighting Power | 1W |
Motor
| Motor Included | Yes, Included |
|---|---|
| Type of Motor | 275W Onboard Motor |
| Noise Level | 50-72 dBA |
Filter
| Filter Type | Stainless Steel Baffle Filter |
|---|---|
| Number of Filters | 1 x Filter |
| Replacement Filter | KITALLFC Filter, Charcoal Filters |
| Filter Feature |
|
Vent
| Exhaust Vent Location | Top |
|---|---|
| Vent Type | Ducted |
| Vent Style | Recirculating or Ducted |
Ducting
| Ducting Availability | Available Separately |
|---|---|
| Ducting Diameter | 150 mm |
| Duct Shape | Round |
| Flue Cover Depth | 295 mm |
| Flue Cover Width | 600 mm |
Recirculation
| Recirculation Option | Top Extraction |
|---|---|
| Recirculation Kit | Available Separately |
Installation
| Assembly Type | Professional Installer Recommended |
|---|---|
| Installation Type | Professional Installer Recommended Undermount |
| Minimum Installation Height from Cooking Surface (Gas) | 650 mm |
| Minimum Installation Height from Cooking Surface (Electric) | 650 mm |
Electrical Connection
| Type of Connection | 10A Plug & Lead |
|---|---|
| Power Cable Length | 1.5 m |
| Wattage/Voltage | 220-240V, 50/60Hz |
| Fuse Rating | 10A |
| Current Consumption | 1,145 mA - 1,270 mA (1.14A - 1.27A) |
Dimensions
| Height | 315 mm |
|---|---|
| Width | 600 mm |
| Depth | 295 mm |
| Product Weight | 12.7 kg |
Packaged Dimensions
| Packaged Width | 71 cm |
|---|---|
| Packaged Depth | 42 cm |
| Packaged Height | 47 cm |
| Packaged Weight | 16.05 kg |
Warranty
| Manufacturers | 60 Months |
|---|
Delivery
We aim to dispatch orders within 2 days. Delivery costs are calculated based on your location and the size of your order. Furniture may take up to 8 weeks to deliver as most products are made specifically for your order. Some Customer Direct products are shipped from overseas and may take longer to arrive. Some goods may take longer to deliver if a product is currently not in stock. A staff member will contact you where this occurs.
Easy returns
If you feel your product has failed a Consumer Guarantee (as defined by New Zealand Consumer Law) then don't worry you can easily return it to your local Harvey Norman store. We'll even pay for the postage if you live in an area where there is no store. Our returns policy covers any purchased item ( conditions apply).
- 1 x Rangehood
- 2 x Stainless Steel Baffle Grease Filters
- 1 x Built-In LED Lighting
- 1 x User Manual and Warranty Information
